Champion Power Equipment 14051 Synthetic Rope Winch Kit, 4,500-lb
#040-5967-4
$299.99
price was $449.99
Save 33% ($150.00)
SaleTop Rated
Buy Online :
- FREEAvailable
- Available
- Available
Pick up at Leduc, AB
4 In Stock
Pick up available 09:00 a.m., Dec 31
Quantity updated to 1
Also Find It in Store:Aisle 37
Only 4 left
at Leduc, AB
Add to Registry
Quebec residents: For information on maintenance and repair click here.
Similar Items
Product Details
Champion’s Synthetic Rope Winch Kit is built to handle the toughest ATV and UTV jobs. Designed for reliability and easy operation, it delivers dependable performance even in demanding conditions. With a focus on reliability and user-friendly operation, this kit ensures you’re prepared for rugged trails and heavy-duty tasks, offering strength and efficiency for a smooth winching experience when it’s needed most.
- Features
- Specifications
- Resources
4500-lb rated line pull powered by a 1.6-horsepower (12-volt) DC motor for reliable strength
Synthetic 38' x 15/64" (11.6 m x 6 mm) rope does not tangle and performs well even under cold temperatures
Gear reduction ratio of 180:1 for smooth, efficient operation
Includes mini rocker switch for easy control from the handlebar
Flat bed mounting channel allows quick installation on ATVs or UTVs
Roller and hawse fairleads enhance rope longevity and protect the vehicle
Kit includes hawse fairlead, mounting channel, mini-rocker switch, clevis hook, contractor/solenoid, battery, and winch cable
| Part Number | 14051 |
|---|---|
| Accessories List | Hook, Mounting Plate, Remote Control, Spooling Clutch, Other |
| Advanced Features | No Advanced Features |
| Assembled Height (cm) | 12.50 cm |
| Assembled Height (ft) | 0.41 ft |
| Assembled Height (in) | 4.92 in |
| Assembled Length (cm) | 34.30 cm |
| Assembled Length (ft) | 1.13 ft |
| Assembled Length (in) | 13.50 in |
| Assembled Weight (kg) | 9.80 kg |
| Assembled Weight (lb) | 21.61 lb |
|---|---|
| Assembled Width (cm) | 11.40 cm |
| Assembled Width (ft) | 0.37 ft |
| Assembled Width (in) | 4.49 in |
| Assembled Width (mm) | 114.00 mm |
| Batteries Required Quantity | 0 |
| Battery Amp Hours (amp-hour) | 0 Ah |
| Cable Length (ft) | 38.06 ft |
| Cable Length (m) | 11.60 m |
| Cord Gauge (ga) | Not Applicable |
| Cord Length (ft) | 0.00 ft |
| Cord Length (m) | 0.00 m |
| Cord Type | Not Applicable |
| Horsepower (HP) | 2 HP |
| Maximum Weight Capacity (g) | 2042000.00 g |
| Maximum Weight Capacity (kg) | 2042.00 kg |
| Maximum Weight Capacity (lb) | 4501.83 lb |
| Motor Type | Not Applicable |
| Number of Pieces | 1 |
| Package Depth (cm) | 41.00 cm |
| Package Depth (in) | 16.14 in |
| Package Height (cm) | 20.50 cm |
| Package Height (in) | 8.07 in |
| Package Weight (kg) | 11.00 kg |
| Package Weight (lb) | 24.25 lb |
| Package Width (cm) | 32.00 cm |
| Package Width (in) | 12.60 in |
| Primary Colour | Black |
| Primary Material | Metal |
| Product Model Number | 14051 |
| Pull Capacity (kg) | 2042.00 kg |
| Pull Capacity (lb) | 4501.83 lb |
Warranty
This product carries a 2 year repair only warranty redeemable at any Canadian Tire store.
Compare Similar Products
Only Show Differences | ||||||
| Ratings | ||||||
| Accessories List | Hook, Mounting Plate, Remote Control, Spooling Clutch, Other | Hook, Mounting Plate, Remote Control, Other | Hook, Mounting Plate, Remote Control, Spooling Clutch, Other | Hook, Mounting Plate, Remote Control, Spooling Clutch | Hook, Mounting Plate, Remote Control, Other | |
| Advanced Features | No Advanced Features | Non-Scratch, Permanent Magnet | No Advanced Features | No Advanced Features | Non-Scratch, Permanent Magnet | |
| Assembled Height (cm) | 12.50 cm | 13.00 cm | 12.70 cm | 10.70 cm | 13.00 cm |
Shop Related Products
- Weekly Deals
- Customers Also Viewed
- Top Trending Products
- More From This Brand
Review Highlights
List of Pros Highlights
Pros
List of Cons Highlights
Cons
Suitable Cons could not be generated at this time.
Reviews
Customer Images and Videos
Filter Reviews
- installation
- purchase
- satisfaction
- price
- for emergencies
- quality
- instructions
- powerful
Rating
Locale
1 to 5 of 171 Reviews
1 – 5 of 171 Reviews
Most Recent
5 out of 5 stars.
Works amazing!!
a year ago
Works awesome install on my RZR and has not let me down or disappointed me in quality or functionality. Have a smaller one on my atv and it’s the same quality.
Helpful?
5 out of 5 stars.
Nice switch
a year ago
I have owned a few champion generators. And the winch is perfect, just like the generators.
Helpful?
5 out of 5 stars.
Amazing products
a year ago
I have only needed to use this twice to get myself out of a muddy mess and both times it pulled me out flawlessly. I've got one on the front and back of my machine. #sweepstake And I just bought another for my 4 wheeler. Once you've used a champion, I think you will agree "champion all the way. I have no complaints or issues with it. Great product!
Yes, I recommend this product.
Originally posted on Champion Power Equipment
4 out of 5 stars.
UTV Winch
a year ago
Champion 4,500 Winch is a nice product
Helpful?
5 out of 5 stars.
Best winch out there!
a year ago
Bought this for a spare. I already have 2 champion 4500’s (front and back) on my atv. They have been there for 5 years. I run them hard and put them away wet. I’ve winched out 1 ton diesel trucks (with snatch blocks) and these winches don’t skip a beat.
Helpful?
1 – 5 of 171 Reviews
Questions
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 23 Questions
Most helpful answers
Q: Will it fit a 2016 defender side by side
2 years ago2 Answers
A: This rope is a replacement length for this specific rated winch. So as long as that was what your original rated winch was then there should lot be an issue. I used this on my UForce 800 side by side.
2 years agoHelpful?
Q: How long is the cable length for the hand control? Is the cable for the hand controller able to be lengthened?
9 years ago2 Answers
A: The remote wiring is 9 feet in length.
9 years agoHelpful?
Q: What is full amperage draw?
11 years ago2 Answers
A: this winch will draw as much as your battery will provide until its dead
11 years agoHelpful?
Q: what is the rope diameter & breaking limit
7 months ago1 Answer
A: Hello, the dimensions for the rope are 15/64 in. (D) x 38 ft. (L), and the max breaking point is 4,500 Lbs. For a more in-depth breakdown of cable capacity, please visit the performance specifications page inside your operator's manual. If you have any other questions, please contact our support team at 877-338-0999 or support@cpeauto.com. - Thank you
7 months agoHelpful?
Q: Bonjour, serait-il possible d'avoir le bolt pattern de ce produit ? Merci
5 years ago1 Answer
- Translate with Google
A: Le modèle de boulon du treuil de 4500 livres est conçu avec un modèle de boulon qui est standard dans cette catégorie de treuil. Il existe des kits de montage pour le treuil May qui utilisent ce modèle de boulon pour la plupart des camions, UTV et VTT populaires.... Les boulons de montage sont M10x20 et doivent être SAE grade 5 ou supérieur et le couple de serrage doit être de 34 ftlb
5 years agoHelpful?
Q: Can someone tell me the bolt mounting pattern? Is it 3”x6.6”?
5 years ago1 Answer
A: The bolt pattern on this unit is . 4.9 in. x 3 in. (12.4 cm x 7.6 cm)
5 years agoHelpful?
Q: Can I use this to pull a 3200lb car onto a hoist or trailer?
6 years ago1 Answer
A: The winch is rated for 4,500lbs of rolling weight. Usually the rule of thumb is to size a winch 1.5 times the vehicle weight. which puts this very close. Additionally, it doesn't sound like the car will be stuck in the mud or on flat tires. Do not use the winch to secure the vehicle for transport. It should be used only for loading and to help control unloading. Thank you!
6 years agoHelpful?
Q: Can this winch be submerged? I want to put it on a side by side and if I do it will see a lot of water.
6 years ago1 Answer
A: The winch is water resistant but not water proof. It should never be fully submerged.
6 years agoHelpful?
Q: PEUT `ON TRAVAILLE AVEC UNE POULIE SUR LE CABLE
6 years ago1 Answer
- Translate with Google
A: Oui, vous pouvez utiliser une poulie pour une traction à deux lignes avec ce treuil. Nous couvrons ces instructions dans le manuel du propriétaire.
6 years agoHelpful?
Q: Bonjour, Est-ce que c'est le même treuil que l' Article #140-0009-8 ? À part le câble synthétique, quelle est la différence ? Merci
6 years ago1 Answer
- Translate with Google
A: Bonjour! Pas exactement. L'article #140-0009-8 a une traction de 5000 livres de ligne, et ce treuil a 4500. En outre, ce treuil comprend un guide-câble par hawse, un interrupteur à bascule miniature, un contacteur, des fils de batterie. L'autre treuil n'inclut pas ces articles.
6 years agoHelpful?
1 - 10 of 23 Questions
