MAXIMUM

MAXIMUM 200A Multi-Process Welder with LCD Screen

#058-7194-0
$899.99
Top RatedExclusive
Buy Online :
Pick up at Leduc, AB
3 In Stock
Free Pick Up over $25 (before taxes)

Pick up available 08:00 a.m., Nov 11

Quantity updated to 1
Also Find It in Store:

Only 3 left

at Leduc, AB
Aisle 22
Add to Registry

Quebec residents: For information on maintenance, repair, and warranty, click here.

MAXIMUM
MAXIMUM

MAXIMUM 200A Multi-Process Welder with LCD Screen

$899.99

Product Details

The MAXIMUM 200A Multi-Process Welder with LCD Screen features dual voltage at 120/230V and supports MIG, Flux Core, Stick, and TIG welding. It includes inverter technology, infinite wire feeding speed and voltage control, and a large LED screen for easy operation. The welder offers a synergic function for MIG, spool gun capability for aluminum, adjustable inductance, 2T/4T selection, spot welding, overheating protection, and adjustable arc-force for excellent Stick performance.

  • Features dual voltage technology at 120/230V

  • Multi-Process Functions: MIG/Flux Core/Stick/TIG

  • Inverter technology

  • Infinite wire feeding speed and voltage control

  • Large LED screen for easy operation

  • Synergic function under MIG for easier welding

  • Available for spool gun function for aluminum welding

  • Adjustable inductance for better welding performance

  • 2T/4T selection function

  • Spot welding capability

  • Overheating protection

  • Adjustable Arc-force with excellent welding performance for STICK

  • Available for 2 lb and 10 lb wire spool

  • Includes: MIG gun, ground cable with clamp, gas hose, regulator, welding cable with electrode holder, 120V adaptor, drive roller, and TIG torch

Part Number 90260960010
Accessories List Consumables, Nozzles, Tips, Torch, Other
Advanced Features Arc Stability, Built- In Stabilizer, Continuous Operation, Stackable, Versatile welding range
Assembled Height (cm) 38.00 cm
Assembled Height (ft) 1.25 ft
Assembled Height (in) 14.96 in
Assembled Length (cm) 49.00 cm
Assembled Length (ft) 1.61 ft
Assembled Length (in) 19.29 in
Assembled Weight (kg) 16.50 kg
Assembled Weight (lb) 36.38 lb
Assembled Width (cm) 22.00 cm
Assembled Width (ft) 0.72 ft
Assembled Width (in) 8.66 in
Assembled Width (mm) 220.00 mm
Certifications CSA Listed
Display Type LCD
Duty Cycle 15
Input Hertz (Hz) 60 Hz
Input Phase 1
Input Voltage (V) 120230 V
Maximum Temperature (°C) 50.00 °C
Maximum Temperature (°F) 122.00 °F
Maximum Weldable Thickness (in) 0.25 in
Maximum Weldable Thickness (mm) 6.40 mm
Minimum Temperature (°C) -20.00 °C
Minimum Temperature (°F) -4.00 °F
Minimum Weldable Thickness (in) 0.02 in
Minimum Weldable Thickness (mm) 0.60 mm
Number of Pieces 12
Output Amperage (amps) 200 A
Output Voltage (V) 24 V
Package Depth (cm) 60.00 cm
Package Depth (in) 23.62 in
Package Height (cm) 44.00 cm
Package Height (in) 17.32 in
Package Weight (kg) 21.30 kg
Package Weight (lb) 46.96 lb
Package Width (cm) 41.00 cm
Package Width (in) 16.14 in
Polarity DC
Power Source Hardwired/Plug In
Primary Colour Black
Primary Material Metal
Product Model Number 90260960010
Welding Process Flux-cored, Inverter, MIG, Multi-Process, TIG, Stick, Wire Feed
Warranty:
  • This product carries a 3 year repair only warranty redeemable at any Canadian Tire store.
User Manual :
  • View user manuals and additional product information

Download

Online Ordering
  • Pick Up is free at most stores (some stores require a minimum order value before tax)
  • Shipping fee is based on size and weight of products and distance from address to store
  • Same-Day Delivery costs $9.99 per order
  • Online Ordering Information
Returns
  • Most products can be returned or exchanged at any Canadian Tire store within 90 days of purchase
  • Some products are non-refundable and non-exchangeable
  • The return policy outlined above may not apply to the product you are currently viewing. For complete details and eligibility, please refer to our Return Policy for exceptions.

Compare Similar Products

Only Show Differences
Ratings
Accessories ListConsumables, Nozzles, Tips, Torch, OtherTips, Torch, OtherConsumables, Nozzles, Other, Tips, TorchConsumables, Nozzles, Other, Tips, TorchConsumables
Advanced FeaturesArc Stability, Built- In Stabilizer, Continuous Operation, Stackable, Versatile welding rangeArc Stability, Built- In Stabilizer, Continuous Operation, Stackable, Versatile welding rangeArc Stability, Built- In Stabilizer, Continuous Operation, Stackable, Versatile welding rangeArc Stability, Continuous Operation, Versatile welding range, Built- In StabilizerArc Stability
Assembled Height (cm)38.00 cm38.00 cm34.00 cm40.60 cm105.00 cm
When we have product recommendations to show you, they'll appear here!

Reviews

Rating Snapshot

Select a row below to filter reviews.
7 reviews with 5 stars.
0 reviews with 4 stars.
1 review with 3 stars.
1 review with 2 stars.
0 reviews with 1 star.

Overall Rating

4.4
6 out of 7 (86%) reviewers recommend this product

Review this product

Select to rate the item with 1 star. This action will open submission form.
Select to rate the item with 2 stars. This action will open submission form.
Select to rate the item with 3 stars. This action will open submission form.
Select to rate the item with 4 stars. This action will open submission form.
Select to rate the item with 5 stars. This action will open submission form.
Adding a review will require a valid email for verification

Filter Reviews

1 to 5 of 9 Reviews.
1 – 5 of 9 Reviews

Machine intéressante, instructions imprécises

a month ago
Nouvelle acquisition. Essayé en mode Stick, MIG et MIG Synergie à date et fonctionne bien. Reste à essayer le mode TIG. La note d’évaluation 3 est donnée à cause des imprécisions et erreurs dans le manuel en ce qui concerne l’assemblage. Ex : Page 15, étapes 3 et/ou 4, installation du connecteur d’alimentation filaire (aussi appelé « pistolet MIG »): On ne mentionne pas qu’il faut dévisser une petite vis à tête moletée, à l’avant du chargeur de fil, afin de pouvoir insérer le bout du connecteur d’alimentation filaire dans la machine. Après l’insertion, on doit resserrer la vis afin de bloquer le connecteur en place dans la machine. Page 17, Étape 8 : Le fil n’avancera pas en suivant les instructions. On doit au préalable sélectionner le type de gaz en utilisant le bouton « Matériaux », laquelle instruction se retrouve seulement à l’étape 14.3

Yes, I recommend this product.

Helpful?

Very Impressed

a month ago
I have been using this welder a couple of months and I must say I'm quite impressed. I haven't welded for a few years but the features on this make setup quite easy. I haven't tried the TIG setup because I don't have a bottle of argon but I will do a review after I've tested it a while. The MIG has been great on a large variety of metal thicknesses that I have tried and I really don't see any difference between this and the larger, dedicated MIG machines I used to work on.

Yes, I recommend this product.

Helpful?

Maximum 200A

2 months ago
Just recently purchased this little over a week ago. I've tried all the functions and seems to work on MIG (with argon mix) TIG and Arc. The MIG set up offers some neat functions , that weren't on previous welders I owned.The TIG part, if you buy this product you will need to purchase tungsten electrodes in the sizes that match the tips and will need a bottle with a 100% Argon gas. I will see how this product holds up over time and use. Price is right.
Helpful?

work really good except one thing

6 months ago
really impress with this welder but I have noticed when I was welding with gas the flow of the tip would stop .... found out the mig whip that goes in the mig connection is not screw on it's just push in & it keep coming loose .... major flaw

No, I do not recommend this product.

Helpful?

Very Impressed!

7 months ago
I have been using this welder for a couple weeks now and I am very impressed. Have only used the stick welding function so far and it is a huge upgrade to my old Miller. The arc-force adjustment is new to me but it really helps maintain a smooth arc. The ease of setting the amperage is very welcome too. I look forward to trying the wire feed and TIG functions.

Yes, I recommend this product.

Helpful?
1 – 5 of 9 Reviews

Questions

1 - 8 of 8 Questions

Q: does it do AC tig

3 months ago
4 Answers
  • A: It does do ac tig your choice of the 110 v or 220 v I bought this machine 4 months ago amd it is absolutely awsome for small stuff around the shop
    3 months ago
    Helpful?

Q: Does the welder support a foot pedal for TIG welding? Does the TIG mode have a high frequency start or is it a lift/scratch TIG welder?

7 months ago
1 Answer
  • A: This welder does support a foot pedal for TIG welding with scratch start as it is not an AC machine. DC only
    3 months ago
    Helpful?

Q: Is this AC/DC welder

8 months ago
1 Answer
  • A: This machine is not AC/DC welder, it is STICK/MIG/DC TIG Welder
    8 months ago
    Helpful?

Q: can this do aluminium welding

8 months ago
1 Answer
  • A: Yes, the machine can do aluminum welding by using a spool gun.
    8 months ago
    Helpful?

Q: Est ce que tous les accessoires pour le mig, tig et baguettes sont inclus ? Si non quels sont les accessoires compatibles ?

9 months ago
Translate with Google
1 Answer
  • A: Tous les accessoires sont inclus pour les procédés Flux-Cored, MIG, TIG et Rods. Il existe un pistolet à bobine en aluminium MAXIMUM (058-7188) qui peut être acheté séparément.
    Anonymous9 months ago
    Helpful?
    Translate with Google

Q: What is the duty cycle of this welder

30 days ago
0 Answers

    Q: Follow up to my question about foot pedal. Is there a part # for compatible foot pedal for TIG amperage control? Is it compatible with standard 7 pin pedal connectors (ie GX7)? Are there requirements for the pedal's resistance (ie 10k, 22k, 47k)?

    3 months ago
    0 Answers

      Q: How well doesnit perform on 120v

      7 months ago
      0 Answers
