Garmin ECHOMAP™ UHD 95sv Chart Plotter Front_Three_Fourths_Angled_Left
Garmin ECHOMAP™ UHD 95sv Chart Plotter Front_Three_Fourths_Angled_Right
Garmin ECHOMAP™ UHD 95sv Chart Plotter Front_Flat
Garmin ECHOMAP™ UHD 95sv Chart Plotter Side_Right
Garmin ECHOMAP™ UHD 95sv Chart Plotter Side_Left
Garmin ECHOMAP™ UHD 95sv Chart Plotter Back_Flat
Garmin

Garmin ECHOMAP™ UHD 95sv Chart Plotter

#178-5199-6
View Product Details
View Similar Items

Quebec residents: For information on maintenance and repair click here.

Garmin
Garmin

Garmin ECHOMAP™ UHD 95sv Chart Plotter

$1,799.99

Product Details

  • Garmin ECHOMAP™ UHD 95sv Chart Plotter features a bright, sunlight-readable 9” (23 cm) touchscreen with keyed assist

  • Included GT56UHD-TM transducer provides Garmin CHIRP traditional sonar and Ultra High-Definition ClearVü scanning sonar and SideVü scanning sonar with 20% greater range

  • Vivid scanning sonar colour palettes make it easy to distinguish targets and structure

  • Preloaded Canada LakeVü g3 inland maps with integrated Navionics® data cover more than 13,000 lakes with up to 1’ (0.3 m) contours

  • Supports Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar

  • Sonar, mapping and user data sharing capabilities with other ECHOMAP™ Plus, ECHOMAP UHD and ECHOMAP Ultra units

  • NMEA 2000® and NMEA 0183 network support for autopilot, engine data and heading sensors, including SteadyCast™ sensor

  • Built-in Wi-Fi® connectivity pairs with the free ActiveCaptain® app for access to OneChart™ to purchase and download new charts; also receive smart notifications, software updates, Garmin Quickdraw™ Community data and more

  • Quick-release bail mount for fast and easy mobility

  • Compatible with Force® trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more

Part Number 010-02525-00
Accessories List Wires
Advanced Features Depth Alarm, GPS Mapping, No Advanced Features, Sunlight Readable, Temperature Readings
Assembled Height (cm) 19.50 cm
Assembled Height (ft) 0.64 ft
Assembled Height (in) 7.68 in
Assembled Length (cm) 29.50 cm
Assembled Length (ft) 0.97 ft
Assembled Length (in) 11.61 in
Assembled Weight (kg) 1.04 kg
Assembled Weight (lb) 2.29 lb
Assembled Width (cm) 9.80 cm
Assembled Width (in) 3.86 in
Assembled Width (mm) 98.00 mm
Backlighting Options LED
Colour Black
Display Resolution Not Applicable
Display Size (cm) 22.90 cm
Display Size (in) 9.02 in
Display Type Touch Screen
Fishing Type General Purpose
Maximum Imaging Depth (ft) 787.40 ft
Maximum Imaging Depth (m) 240.00 m
Memory Type Internal, MicroSD
Mount Style Gimbal, Quick Release
Operating Frequency (kHz) 150.00 kHz
Package Depth (cm) 20.40 cm
Package Depth (in) 8.03 in
Package Height (cm) 20.90 cm
Package Height (in) 8.23 in
Package Weight (kg) 3.50 kg
Package Weight (lb) 7.72 lb
Package Width (cm) 33.90 cm
Package Width (in) 13.35 in
Power Source Hardwired/Plug In
Primary Material Plastic
Smart System Compatibility Android, IPhone
Wattage 12 W
