Product Details
The Milescraft® PocketJig200™ allows you to connect your workpieces quickly with strong and accurate pocket hole joints. Create corner joints, edge joints, T-joints, framing joints, miter joints, and make repairs. With built-in settings for different board thicknesses, just set this pocket jig to your desired setting, set the depth of your bit, and start drilling. This complete kit in a sturdy carrying case comes with all of the bits, drivers, screws and accessories needed to complete any pocket hole project.
PocketJig200™ Pocket Hole Jig Kit – Designed To Make Repairs Simple: Spring-loaded sled adjust button allows the jig to be set to do repairs of any nature around your home or your shop
Built-In Imperial and Metric Scales: The built-in scales allow you to easily measure the thickness of your workpiece
Board Thickness Settings: There are four common board thickness settings built into the pocket jig: 1/2″, 3/4″, 1″ and 1-1/2″ (12, 19, 27, 38mm) with easy readout arrow to help define your board thickness setting while you can easily adjust to your board thickness setting with the single sled design and sled adjust button
Hardened Steel Drill Bushings: For precise and accurate pocket holes every time using the Milescraft PocketBit™. Has tight tolerances between the bushing and the drill bit, reduce tear-out and create a clean pocket hole on the first try
Recessed Clamp Pocket with Magnet: Helps to keep the clamp in the same position as you move to different locations with the stronger rare earth magnet, you can easily clamp the jig from one location to another
Built-In imperial and metric scales to measure board thickness
3/8″ HSS Step Drill Bit: Made from high-speed steel the PocketBit with a 1/4″ hex shank is designed to reduce clogging and provide smooth and precise holes
3/8″ Anti-roll, Split Design Stop Collar: The split design prevents slipping of the set screw when tightened and prevents the bit from rolling. Includes hex key for tightening and accepts all 1/4" hex bits
Quickly and easily change from drilling to driving
3″ and 6″ Magnetic T20 Torx® Drivers: for maximum torque settings without stripping and allows pocket screws to align with maximum precision
Rugged Storage Case: With designated places for components, you will never have to go digging through your toolbox for your pocket hole jig again
| Part Number | 13310003 |
|---|---|
| Drill/Driver Bit Type | Woodboring Drill Bits |
| Primary Material | High-Speed Steel |
| Coating | No Coating |
| Number of Pieces | 15 |
| Shank Type | Straight |
| Product Use(s) | Wood |
| Accessories List | Hard Case |
| Advanced Features | No Advanced Features |
| Assembled Weight (lb) | 1.10 lb |
| Assembled Height (cm) | 12.07 cm |
|---|---|
| Assembled Height (in) | 4.75 in |
| Assembled Length (cm) | 5.72 cm |
| Assembled Length (in) | 2.25 in |
| Assembled Width (cm) | 5.72 cm |
| Assembled Width (in) | 2.25 in |
| Bit Diameter (Size) | 3/8" |
| Shank Size (in) | 0.38 in |
| Shank Size (mm) | 9.65 mm |
