Mastercraft
Mastercraft 115V Flux Core 125i Inverter Welder
#058-1926-6
$299.99
Top RatedExclusive
Buy Online :
- FREEAvailable
- Available
- Available
Pick up at Leduc, AB
8 In Stock
Pick up available 08:30 a.m., Jan 03
Quantity updated to 1
Also Find It in Store:
8 In Stock at Leduc, AB
Aisle 22
Add to Registry
Quebec residents: For information on maintenance and repair click here.
Similar Items
Product Details
The Mastercraft 115V Flux Core 125i Inverter Welder is a lightweight welding unit designed for portability and efficient operation. With a consistent weld arc and voltage control, this versatile inverter welding unit comes with a 6-ft grounding cable, clamp, 6-ft flux core MIG torch and a belt for your convenience. The compact size and lightweight design make this the perfect welder for job sites away from home.
Requires no gas making it perfect for jobs on-the-go
DC power creates a smooth, stable weld arc
Infinite wire speed and voltage control lets you adjust the output to your needs
Built with thermal overload protection
Can use 0.030", 0.035" flux-cored wire
115V 1 Phase input
Duty cycle: 30% at 90A
Weld metal thickness: 18 gauge-3/16" (1.2-4.75mm)
| Part Number | 90260710024 |
|---|---|
| Minimum Weldable Thickness (in) | 0.05 in |
| Maximum Weldable Thickness (in) | 0.19 in |
| Minimum Weldable Thickness (mm) | 1.20 mm |
| Maximum Weldable Thickness (mm) | 4.80 mm |
| Input Voltage (V) | 120 V |
| Output Amperage (amps) | 125 A |
| Duty Cycle | 30 |
| Welding Process | Flux-cored, Inverter, Wire Feed |
| Output Voltage (V) | 20 V |
| Certifications | CSA Listed |
|---|---|
| Assembled Height (in) | 12.99 in |
| Assembled Weight (lb) | 17.20 lb |
| Primary Material | Metal |
| Primary Colour | Blue |
| Polarity | DC |
| Accessories List | Nozzles, Other, Tips, Torch |
| Number of Pieces | 1 |
| Power Source | Hardwired/Plug In |
| Display Type | No Display |
| Advanced Features | Continuous Operation, Versatile welding range |
| Input Hertz (Hz) | 60 Hz |
| Assembled Width (in) | 17.13 in |
| Assembled Length (in) | 9.06 in |
Warranty
- 3 yr repair warranty. This product has replaceable parts. For details contact MASTERCRAFT Customer Support at 1-800-689-9928
Online Ordering
- Pick Up is free at most stores (some stores require a minimum order value before tax)
- Shipping fee is based on size and weight of products and distance from address to store
- Same-Day Delivery costs $9.99 per order
- Online Ordering Information
Returns
- Most products can be returned or exchanged at any Canadian Tire store within 90 days of purchase
- Some products are non-refundable and non-exchangeable
- The return policy outlined above may not apply to the product you are currently viewing. For complete details and eligibility, please refer to our Return Policy for exceptions.
Compare Similar Products
Only Show Differences | Currently Viewing | |||||
| Ratings | ||||||
| Minimum Weldable Thickness (in) | 0.05 in | 0.04 in | 0.02 in | 0.05 in | 0.00 in | |
| Maximum Weldable Thickness (in) | 0.19 in | 0.19 in | 0.25 in | 0.19 in | 0.63 in | |
| Minimum Weldable Thickness (mm) | 1.20 mm | 1.00 mm | 0.60 mm | 1.20 mm | 0.00 mm |
Shop Related Products
- Weekly Deals
- Customers Also Viewed
- Top Trending Products
- More From This Brand
Weekly Deals
Review Highlights
List of Pros Highlights
Pros
List of Cons Highlights
Cons
Suitable Cons could not be generated at this time.
Reviews
Customer Images and Videos
Filter Reviews
- purchase
- price
- satisfaction
- small
- size
- setup
- quality
- compact
Rating
Locale
1 to 5 of 81 Reviews
1 – 5 of 81 Reviews
Most Recent
5 out of 5 stars.
Compact MIG Welder
3 days ago
This welder works great if you have prior experience with welding. It was easy to set up and was available for a great price. Remember to buy 0.003" wire, welding gloves and a certified welding helmet to use with it because it does not come as a kit. Wear clothing that will withstand hot sparks and have water nearby.
Helpful?
5 out of 5 stars.
awesome
a month ago
Works awesome.very compact
Helpful?
5 out of 5 stars.
Simple et facile à utiliser
4 months ago
4 out of 5 stars.
Bonne petite soudeuse
5 months ago
Bonne petite soudeuse. Fonctionne très bien. Cette soudeuse est ideal pour les débutants et les petits projets personnel. En vente c'est un achat sure. Tres satisfait.
Translate with GoogleHelpful?
5 out of 5 stars.
Awesome unit
5 months ago
For someone with absolutely 0 knowledge of welding I was able to stick some metal together. Very happy with this purchase
Yes, I recommend this product.
Helpful?
1 – 5 of 81 Reviews
Questions
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 31 Questions
Most helpful answers
Q: I'm thinking of buying this in the next few days. But I'm just wondering if can I just plug-in to outlet in my garage which has a 15A circuit? and would this be any danger to cause any fire? Thnaks
4 years ago5 Answers
A: Welder will run on 15 amps okay for short periods but just be aware that you are at greater risk of eventually throwing a breaker.The recommended operating circuit for this welder is ideally a 20 amp circuit for optimum performance and reliability.
3 years agoHelpful?
Q: Is this inverter model noticeably better than the older 120v model? I know these welders are worth their weight in gold but is this inverter one worth the extra pennies or just stick with the older one and save some money?
a year ago3 Answers
A: This is the best 120 volt flux core welder I have ever used. I have been a journeyman welder for over 40 years.
a year agoHelpful?
Q: I am trying to use this welder with mastercraft 16 gauge 50' yellow power cord. 15 amp breaker is not holding circuit when I just try to weld. It is not even cycle, just first touch to the metal. Am I doing something wrong or machine has issue?
a year ago3 Answers
A: I have got this power cord from Canadian Tire specifically for this welder. I will ask them to change it if problem is related to power cord. When I ask question, they usually say, they are licensed or certified to help but very not nice situation.
a year agoHelpful?
Q: Bonjour, quel et le courant secteur (120vAC) nécessaire pour cet appareil? Merci!
3 years ago3 Answers
- Translate with Google
A: Son courant d'entrée demandé est de 20A
3 years agoHelpful?
Q: Can this be used to wled stainless steel?
4 years ago3 Answers
A: This welder can weld stainless steel if use self shielding stainless wire.
3 years agoHelpful?
Q: Est-elle capable de souder de l'aluminium?
a month ago2 Answers
- Translate with Google
A: Non. Pour souder de l’aluminium, il faut du courant alternatif et le gaz de protection du bain de fusion. Il faut également un spool gun spécifique pour l’aluminium car le mécanisme original d’avance du fil est conçu pour un matériel beaucoup plus dur que l’aluminium.
23 days agoHelpful?
Q: Can you use the 11lb rolls of wire?
a year ago2 Answers
A: No unit is portable extremely light weight and that's is whole idea behind it ... But it can weld heavier metals no problem.
a year agoHelpful?
Q: The contact tip item number is not stated in the manual. Can you tell me the mastercraft number?
3 years ago2 Answers
A: The part number at the store for the .030 tip, is 058-9622-0. It is not visible to me online here as of May 1, 2022. Cheers.
3 years agoHelpful?
Q: Will it weld 1/8 inch aluminum?
4 years ago2 Answers
A: No, the machine only welds using flux core wire which is for iron/steel material.
4 years agoHelpful?
Q: Can you purchase replacement nozzles for this welder? I can’t find any on the website. I’m not looking for the contact tip. The nozzle goes over the contact tip.
4 years ago2 Answers
A: The fluxcore nozzles are bit harder to find but the mig nozzles work too and some prefer them because they shield the tip from grounding out .
4 years agoHelpful?
1 - 10 of 31 Questions
