Mastercraft 5-Gallon Oil-Free Portable Air Compressor, 135 PSI, 1.5HP
#058-9315-2
$395.99
Exclusive
Unfortunately, this product is discontinued in your selected store and nearby stores.
You may be interested in these similar products shown below.Similar Items
Quebec residents: For information on maintenance and repair click here.
Similar Items
Product Details
Mastercraft 5 Gallon Air Compressor features 135 max PSI, 1.5 running HP and is oil free for less maintenance
Metal control panel with two metal case gauges, two quick couplers for each operation
Reinforced handle to well protect the pump/motor from damage
Metal air filter for durabilty
4.8CFM@40PSI, 3.5CFM@90PSI
5-gallon twin stack provide stable air flow
1.5 running HP induction motor
Oil free for less maintenance
Working pressure: 105-135psi
Product Dimensions: 18 x 15.7 x 20.6" (45.5 x 40 x 52.5 cm)
Net weight: 51.3 lbs (23.30 kg)
| Part Number | 0320513A |
|---|---|
| Compressor Style | Twin Stack |
| Tank Capacity (gal) | 5.00 gal (US) |
| Tank Capacity (l) | 18.93 l |
| Maximum Pressure (psi) | 135 lb/in² |
| CFM @ 90 PSI | 4 lb/in² |
| CFM @ 40 PSI | 5 lb/in² |
| Maximum Air Flow Capacity (ft³/min) | 303.71 ft³/min |
| Maximum Air Flow Capacity (m³/min) | 8.60 m³/min |
| Horsepower (HP) | 2 HP |
| Pump Lubrication | Oil Free |
|---|---|
| Cord Type | Corded |
| Cord Gauge (ga) | 16ga |
| Motor Type | Induction |
| Number of Motors | 1 |
| Noise Level (dB) | 88 dB |
| Number of Stages in Compressor | Single Stage |
| Air Outlet Size (in) | 0.39 in |
| Accessories List | No Accessories Included |
| Advanced Features | Coupler, Gauge Indicator, Handle, Metal Intake Filter, Regulator |
| Batteries Required Quantity | 0 |
| Product Use(s) | Blow Cleaning, Brad Nailing, Commercial, Inflation, Portable, Stationary |
| Primary Colour | Black |
| Primary Material | Poly |
| Certifications | ETL Listed, UL Listed |
| Assembled Length (in) | 17.91 in |
| Assembled Width (in) | 15.75 in |
| Assembled Height (in) | 20.67 in |
| Assembled Weight (lb) | 55.78 lb |
| Amperage | 12 A |
| Number of Accessories | 0 |
| Product Model Number | 0320513A |
Warranty
- This product carries a 3 year repair only warranty redeemable at any Canadian Tire store.
Online Ordering
- Pick Up is free at most stores (some stores require a minimum order value before tax)
- Shipping fee is based on size and weight of products and distance from address to store
- Same-Day Delivery costs $9.99 per order
- Online Ordering Information
Returns
- Most products can be returned or exchanged at any Canadian Tire store within 90 days of purchase
- Some products are non-refundable and non-exchangeable
- The return policy outlined above may not apply to the product you are currently viewing. For complete details and eligibility, please refer to our Return Policy for exceptions.
Compare Similar Products
Only Show Differences | |||||
| Ratings | |||||
| CFM @ 90 PSI | 4 lb/in² | 5 lb/in² | 0 lb/in² | 3 lb/in² | |
| CFM @ 40 PSI | 5 lb/in² | 6 lb/in² | 0 lb/in² | 4 lb/in² | |
| Accessories List | No Accessories Included | No Accessories Included | No Accessories Included | No Accessories Included |
Shop Related Products
- Weekly Deals
- Customers Also Viewed
- Top Trending Products
- More From This Brand
Weekly Deals
Review Highlights
List of Pros Highlights
Pros
List of Cons Highlights
Cons
Reviews
Customer Images and Videos
Filter Reviews
- purchase
- price
- satisfaction
- hose
- small
- noise level
- value
- portable
Rating
Locale
1 to 5 of 127 Reviews
1 – 5 of 127 Reviews
Most Recent
5 out of 5 stars.
Does the job
2 years ago
Bought a couple E-Bikes and we like to ride the rail trail which is packed gravel and can leave the bikes dusty. I like that I can dial down the pressure and use the blower to clean the bikes without using water. Also comes in handy for inflating tires. Don't have to do much carpentry but good to know I can use it for replacing trim etc. if I had to. Didn't hurt that I got it for 50% off either.
Helpful?
5 out of 5 stars.
Great value
2 years ago
Great compressor... I did not expect it to perform as well as it did, very portable and loved that you can actually control the output ports (to bled out the air line before connecting and or disconnecting your airlines).
Helpful?
5 out of 5 stars.
pressurre
2 years ago
the best thing u got
Helpful?
5 out of 5 stars.
Efficace
2 years ago
4 out of 5 stars.
Tres bon achat
2 years ago
1 – 5 of 127 Reviews
Questions
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 38 Questions
Most helpful answers
Q: Bonjour, est-ce qu'on peut l’entreposer dans un garage non chauffer? Et, fonctionne-t-il au froid?
4 years ago3 Answers
- Translate with Google
A: Le compresseur peut être stocké dans un garage non chauffé mais il sera difficile à démarrer en cas de grand froid. La température de travail recommandée est de -10℃ à 35℃.
4 years agoHelpful?
Q: I connected a 50ft 3/8 hose and I cannot run any of my tools due to low pressure. Should this support any length of hose? It works with my 20 foot 1/2 hose.
4 years ago2 Answers
A: I have only run a brad nailer for tools and it worked fine
4 years agoHelpful?
Q: What size is the connector for the air lines? 1/4, 3/8, etc..
4 years ago2 Answers
A: Its standard plug and play that you get with the majority of air tools.
4 years agoHelpful?
Q: would this unit be able to inflate a motorhome tire to 100 pounds size is 275-70x22.5
9 years ago2 Answers
A: Yes, it will. With all due respect to the Canadian tire team, they must be misreading the specs (perhaps reading the CFM at 90PSI). This compressor is rated at 135 PSI. That is written right on the cover of the manual (I'm looking at it right now). It's also listed on page 5 of the manual on the Technical Specifications page: "Maximum Pressure (PSI) 135". It's again mentioned on page 10 of the manual: "maximum P = 135 PSI". Furthermore, it is written on the bottom of every single page of the manual: "135 PSI (Max) Air Compressor". 135 PSI is written on the box. 135 PSI is written on the compressor itself. I have used this compressor to fill a portable air tank to over 120 PSI. It will certainly fill a tire to 100 PSI
9 years agoHelpful?
Q: Does the 5 gallon twin tank air compressor able to sustain the use of a roofing gun? Thank you.
10 years ago2 Answers
A: Recently used it for that. Worked just fine.
9 years agoHelpful?
Q: Can you set the cut-in and cut-out pressure?
11 years ago2 Answers
A: You can only set the outgoing air pressure going to the tool.
10 years agoHelpful?
Q: Is there available parts for this just incase(piston gasket)if it worns out?
11 years ago2 Answers
A: No , No parts, no service.
11 years agoHelpful?
Q: Can this be used to spray paint or stain?
11 years ago2 Answers
A: Yes, it's got plenty of pressure and volume to use any type of instrument - impact gun, nail gun or spray gun.
10 years agoHelpful?
Q: Is there a reset button
3 years ago1 Answer
A: Is there a reset button
3 years agoHelpful?
Q: Combien de pieds cubes par minutes à 90 livres? On indique 3 livres par pouces cube, ce qui est une mesure de pression quand on cherche une mesure de volume d'air. Vos descriptions de produits sont régulièrement pleins d'erreurs.
4 years ago1 Answer
- Translate with Google
A: Désolé, je ne sais pas. J'ai utilisé ce compresseur avec des "nailer" GA16, GA18 et aussi avec un GA23. sans aucune faiblesse de sa part. Bon outil pour la tâche. Je l'avais aussi acheté pour peut-être peinturer des armoires mais finalement le projet a changé. Bonne chance -Mario
4 years agoHelpful?
